Top quality factory production 200T complete wheat corn flour mill process line

FOB Reference Price:Get Latest Price
$35,000.00 - $238,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
MDDK completely line
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 90 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Warranty:
1 year
After-sales Service Provided:
Online support, Engineers available to service machinery overseas
Place of Origin:
Shaanxi, China
Brand Name:
Fire Phoenx
Voltage:
220V/380V
Weight:
7T~370T
Certification:
ISO9001
Production Capacity:
72-85%/75%-90%
Dimension(L*W*H):
2050*1450*2050mm
Power(W):
according to customers
Applicable Industries:
Food & Beverage Factory
Name:
Top quality factory production complete wheat flour mill process line
Product name:
Multifunctional Grain Grinder
Raw material:
Wheat Maize Corn
Application:
Grain Processing Line
Usage:
Powder Making
Type:
Grain Processing Equipment
Final products:
Super Fine Flour
Color:
Blue / white blue/ green /white green
Capacity:
50-1000T/D
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
We will pack by the protect film inner, water-repellent plastic outside. The wood packing is necessary If send by less than a container. The machine will fixed by steel rope in the container. Make sure it is in good condition when arrived destination.
Port
shanghai port, xingang port, dalian port, qingdao port.
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 90 To be negotiated
Video Description

Top quality factory production 200T complete wheat corn flour mill process line

Design specification







Brief Description

This scheme using corn as raw materials, processing corn, wheat, soybean ect. We set up an automated production lines, including cleaning, stone, magnetic separation and dust removal, atomized water, peeling, degerming, polishing, grinding milling, flat screen section powder, flour, quantitative packaging, transportation, etc.







Technology



It is an intelligent surface grinding machine with the highest degree of automation.

  • Turkey's advanced technology.
  • The whole machine adopts modular parts, flexible and flexible.
  • All appliances, controls and the use of speed are quick and accurate responses.
  • The whole machine can be fully opened and exposed on key parts, which can be easily maintained and cleaned.

Turkey's technology is a perfect combination of Chinese manufacturing.

It is an intelligent surface grinding machine with the highest degree of automation.The whole machine adopts modular

component integration and flexible functional changes.The whole machine can be fully opened and exposed on key parts, which can be easily maintained and cleaned.

We can also provide corn, wheat, barley flour mill, coarse mill, 10 tons, 20 tons, 30 tons, 50 tons, 100 tons.We can remove the husks, faucet and germ from the corn and

make the flour and coarse grain have a good color and taste.The company is a professional production, production, operation, production, operation, production, operation,

production, operation of the enterprise.

Our team of engineers can design many different projects based on your specific requirements.We can offer small wheat flour mill, every 20 tons, 50 tons, 60 tons, 80 tons,

100 tons, 120 tons, 150 tons, 200 tons, 300 tons, 500 tons, 1000 tons, 24 hours, we can offer the transfer key project.Engineers will fly to your country to install and teach you

how to use the machine.



TypeProductPower(k w)Capacity(t/24hr)Workshop Size(L*W*H)m
100t

Special purpose flour Grade |

Grade ||

Standard flour (co-production)

34010035*10*11
120t42012043*10*11
140t53014047*10*11
150t54015049*10*12.5
160t59816049*12*12
200t72215054*12*12.5





Features

FLow Chart

Ⅰ,Cleaning Section





This series of production lines cleaning part use 6 times cleaning machines. In the cleaning section, there are several aspiration systems which can reduce the dust spray-out from the machine and keep a good working environment.This is a complicated thorough flow sheet which can remove most of the coarse offal, middle size offal and fine offal in the grain. The cleaning section is not only suitable for grain imported with lower moisture and but also suitable dirty grain from local customers.

Ⅱ,Milling And  Section





In the milling and sieve section, there are four types of systems to mill the wheat to flour. They are 5-Break system, 7-Reduction system, 2-Scratch system and 2-Tail system. Purifiers are specially designed to get more pure semolina sent to the Reduction which improves the flour quality by a large margin. The rollers for Reduction, Semolina, and Tail systems are smooth rollers which are well blasted. The whole design will insure less bran mixed into the bran and the flour yield is maximized. Because the well designed pneumatic lifting system, the whole mill material is transferred by High pressure fan. The milling room will be clean and sanitary for aspiration adoption.







Packing Electricl

Break System

Break system mainly function:

1. Break the wheat and scrape the endosperm particles off

2. Try to keep the bran intact and keep the flour out of bran

3. An ideal and perfect Break system should produce only large bran flakes and coarse wheat residues, but not fine bran powder.The production of fine bran powder is inevitable, but the residues, but not fine bran powder.The production of fine bran powder is inevitable.

Break system is best carried out step by step to obtain the best separation efficiency. It is prepare for Reduction System.



Reduction System

1. The wheat residue and wheat heart extracted from the Break system are ground into fine flour by sifting and classifying and purifying.

2. Grind the bran crumbs and wheat germ as lightly as possible and sift them away from the flour

3. All kinds of the endosperm of different size particles, often called the coarse slag, slag, slag, pin,  etc., can't be a ground into a powder, can only gradually to make them thin, every grinding out a certain amount of powder, materials that do not meet the flour fineness requirement to continue to grind, under a chip at the same time gives off a small amount of bran and wheat germ, and prevent them from affect the quality of the powder of the posterior heart mill system.



 Scratch system
After this milling the bran and big grit delivery to the next scratch system. little grit and clean germ will send to the pre-reduction system


Ⅱ,Packing Part

All  packing machines are automatic.The packing machine has advatages of high measuring accuracy, fast packing speed, reliable and stable working. The packing machine has function of fault self-diagnosis. Its sewing machine has automatic sewing and cutting function. The packing machine is with sealed type bag-clamping mechanism, whih can prevent material from leaking out.There are many types of specification like 1-5kg,2.5-10kg,20-25kg,30-50kg.The clients can choose different packing specification according to requirements.

Ⅲ,Electrical Control And Mabagement

In this part, we will supply electrical control cabinet, signal cable, cable trays and cable ladders, and other electrical installation parts.  With PLC control system, all the machinery will be controlled by Programmed Logical Controller. This will insure the stable operation of machinery. The system will make some adjustments automatically  when any machine is in fault or stopped abnormally. In the same time it will alarm and remind the operator to settle the faults.Schneider series electrical parts are used in out electrical cabinet. The PLC brand will be Siemens, Omron, Mitsubishi and other International Brand. The combination of a good designing and reliable electrical parts will insure a long-life service.



Company Information







Company Information



Hanzhong Burt Machinery Co.Ltd is a professional manufacturer. Our group product flour milling machine, wheat washing machine and many types food

or seed dryer almost 30 years.Our products have a number of patents and certification.  Our products always export to western Asia, Africa, South America

and dozens of other countries.We have a perfect overseas service system and team.If we are lucky enough to cooperate, we can solve the after-sales problem

quickly and professionally.

We have advanced technology research and development team, and have obtained ISO9001 product certification and many technical patents.



Exihition



Our company has participated in the Canton fair several times, the sino-kazakhstan trade conference and other large international conferences, and has received wide recognition and support from customers



 Customers feedback:





Our Services



1. Free consultation service before, during, and after sales;
2. Free project planning and design services;
3. Free debugging of equipment until everything is functional;
4. Free long distance shipping management from seller's factory to named place by buyer;
5. Free maintenance and operating training personally;
6. Free new production techniques and formulas;
7. Provide online video inspection before delivery.Remote client display details for the upcoming machine.
8. Provide 1 year complete warranty and life-time maintenance service
